LED Street Lighting

Product Name：LED Street Lighting

Basic info：Lumileds Luxeon 3030;
Super long lifetime(Lumen maintenance);
Wide applicability for complex situations;
High versatility apply for all sorts of lamps retrofit;
High quality surface treatment.
After special treatment, the module can be used in coastal areas, high ultraviolet areas and other special environments.

Download Projects LED street Lights Service

Quality

One year warranty and lifelong maintenance

Cooperation

OEM/distribution, agency

Pre/after sales

Fast response within 24 hours

Introduce Technology data 3D

Specification

Input Voltage:  100 ~ 240Vac
Input Frequency:  50 / 60Hz
Power Factor (PF):  0.95
Surge Protection Level: 10kV line-earth
Operating Environment: -40℃~ +50℃, 10% ~ 90% RH
Color Temperature (CCT)*:  3000K, 4000K, 5000K, 5700K
Color Rendering Index (CRI):  ≥70
Housing:  Die-cast Aluminum
IP Rating of LED Light Engine:  IP68
IP Rating of Luminaire:  IP67
Impact Protection Level:  IK08
Warranty:  5 Years Limited

Features

Construction
· Die-cast aluminum housing.
· Unique patented IP68 (highest protection level) LED light engines.
· Whole structure heating dissipation design with best thermal conduction and radiation.
· IP67 rated luminaire.
Distribution
· Ergonomic and dedicated lighting distributions are available for various roadway applications.
Control
· Sensor available (on/off).
